IR Motion Touchless Switch - Dual Mode Speed Adjustable for Automatic Door

This wireless IR touch-free switch is specially designed for automatic doors, adopting 38KHz infrared modulation technology. It triggers door opening by inducting human body/reflective surface in a contactless way, no touch required throughout the process, which is hygienic and convenient. The product supports stepless adjustment of 3-18cm induction distance, is equipped with M normal/K high-speed dual induction modes (K mode with 26% faster response speed), and also has free switching between momentary/latching dual output modes. The self-learning code design can pair up to 20 transmitters with a wireless obstacle-free transmission distance of over 30 meters. Compatible with DC12~30V wide voltage power supply, both the receiver and transmitter have compact bodies for easy installation, with low power consumption and long battery life—the transmitter can last about 190 days with 200 uses per day. With a receiving sensitivity of -95dbm and stable signal transmission, it is widely applicable to various automatic door scenarios to realize intelligent hands-free door opening.

Products
Technical Data
Downloads

Product description

1. Touchless IR induction, 3-18cm adjustable distance, hands-free opening for better hygiene

2. M/K dual induction modes, K mode 26% faster response, fits different induction needs

3. Dual output modes, M momentary/L latching, one-click switch for auto door logic

4. Self-learning code pairing, stores 20 transmitters, convenient for multi-device control

5. 30M wireless transmission, -95dbm high-sensitivity reception, stable signal no delay

6. 38KHz IR modulation, anti-interference no cross-frequency, accurate induction no false trigger

7. One-click code clear, 5s long press to delete all codes, efficient and simple operation

8. Low power long life, transmitter 200 uses per day for about 190 days

9. DC12~30V wide voltage support, compatible with all auto door controller power supplies

10. Compact & thin body, space-saving installation, easy wiring and debugging

11. 1A 24VDC contact capacity, 1.5s precise momentary signal, strong compatibility

Authentication

Wireless IR Touch-Free Switch for Auto Door- Office/Shop Auto Door Induction Open Real Shot

Real-scene usage of this IR touch-free switch for automatic door is here!The video shows the switch installed on the automatic door in real scene: when people enter/exit and approach the induction area, no touch to the switch is needed, the 38KHz infrared senses instantly and accurately, the door opens smoothly with zero delay, and closes normally when people leave. The whole process is hands-free for better hygiene, no jitter and no false trigger!The switch supports 3-18cm adjustable induction distance, free switching between M normal/K high-speed dual modes, and momentary/latching dual output for different automatic doors. It features 30M stable wireless transmission, can pair 20 transmitters, and is compatible with all automatic doors with DC12~30V wide voltage. With low power consumption and long battery life, install it on automatic doors of offices, shops and residential communities to easily realize intelligent hands-free door opening!

Technical data

Wireless receiver
Power supply:	DC12~30V
Static current:	34mA(DC12V)
Action current:	62mA(DC12V)
Main contact capacity:	1A 24VDC
Contact suction holding time:	1.5Seconds
Product size:	110(L)x30(W)x15(H)mm
Transmitter
Power supply:	3V(2pcs 3V button battery)
Standby current:	S22μA(M mode)40μA(K mode)
Emission current:	10mA
Touchless sensing distance:	3~18cm
Infrared modulated frequency:	38KHz
IR scan interval:	M mode:330ms K mode:250ms
Battery Life:	200 times/day,about 190 days
Receiver sensitivity:	-95dbm
Emission distance:	Over 30 meters in no obstacles area
Product size:	135(L)x36(W)x10(H)mm
