OUTUS ORD120A 120KG Sliding Door System – Plug-and-Play 60-Min Install

1. High Load Adaptation, First Choice for Commercial Use：Max. load capacity of 150kg for single leaf door and 2×120kg for double leaf doors, stably bearing the high-frequency passenger flow demand of office buildings, shopping malls and other places;

2. Brushless Motor, Quiet & Smooth：55W high-power brushless motor with low operating noise and smooth, jitter-free opening/closing, suitable for places with quiet environment requirements;

3. Knob Precision Adjustment, Easy Operation：Full knob-type parameter adjustment without professional programming, quickly and precisely setting opening/closing speed, buffer distance and hold-open time;

4. Full Accessory Integration, Worry-Free Installation：Comes as a standard set including rails, motor, controller, belt, hanger and other standardized accessories, ready to use and compatible with standard installation;

5. Multi-Mode Operation, Flexible Adaptation：Supports left/right door opening direction switching and auto/signal closing mode selection, adapting to single/double leaf doors and different passage scenarios;

6. International Certification, Safe & Durable：CE certified, with multiple safety mechanisms such as excessive resistance and overload protection, durable and in line with safety specifications;

7. Wide Temperature Operation, Environmentally Friendly：Working temperature range of -20℃~+50℃, adapting to different climate environments and ensuring long-term stable operation.

Products
Technical Data
Downloads

Technical data

Parameters and specifications
Power supply voltage	AC220V ±10%, 50-60Hz 2A
Rated voltage	55W
Opening width	Double sliding door:650 - 1250 Single sliding door: 750 - 1600
Door leaf weight	Dual Open: max. 2 × 120KG Single open: max. 1 × 130KG
Door leaf running speed	Opening speed: 150 - 460mm/s Closing speed: 150 - 460mm/s
Environment conditii	Temperature range: -20℃ ~ +50℃

Product description

The ORD120A Automatic Door System is a cost-effective automatic sliding door solution specially designed for medium and large commercial places, with a maximum load capacity of 150kg (single leaf). It is widely used in office buildings, shopping malls, hospitals, hotels and public passages. The system integrates a 55W brushless motor and an intelligent controller to achieve a smooth and low-noise operation experience. Equipped with a full set of installation accessories and standard rails, the product supports flexible switching between single/double leaf doors and is compatible with various frame materials such as glass and metal doors. The controller features knob-type precise speed regulation, allowing free setting of opening/closing speed, buffer distance and hold-open time. It seamlessly connects with peripherals such as sensors, safety light curtains and access control. Compliant with CE international certification standards, it ensures stable operation and excellent environmental adaptability, providing a one-stop purchasing and installation service for commercial automatic doors.

Authentication

Unboxing Real Shot! ORD120A Automatic Door System - Full Set of Original Accessories Specification Display

This video is a HD real-shot display of the full set of original accessories for the ORD120A commercial automatic door system, comprehensively presenting the details, specifications and adaptability of the core system accessories. The video showcases one by one: ① 55W brushless motor (24-hour aging test); ② Intelligent controller (with knob adjustment and test button); ③ Thickened aluminum alloy rails (125mm/180mm optional specifications, 2.1M/2.4M/3M/4.2M custom lengths); ④ Synchronous belt, tension pulley, hanger assembly; ⑤ Wiring terminal set, sensor plugs and installation screw kit. All accessories are custom-made for ORD120A, selected with high-quality materials to perfectly adapt to single/double leaf door installation needs. The standardized accessory design, combined with clear terminal identification and installation tutorials, allows professional installers to get started quickly, ensuring stable and durable operation of the automatic door system. Follow us for more ORD120A installation commissioning and troubleshooting skills!
