outus Automatic Sliding Glass Door Aluminum Sliding Door System unit

outus Automatic Sliding Glass Door Aluminum Sliding Door System unit

✔  Power supply voltage: Ac220V ± 10%, 50-60Hz 2A

✔  Opening width:Double sliding door: 65~1250mm,Single sliding door: 750~1600mm

✔  Door opening and closing speed is adjustable from 150mm/s to 460mm/s

✔  Door leaf weight:Double opening sliding door: max.2 x 125KG,Single sliding door: max.1 x 150KG

✔  Intelligent sensor opening and closing

✔  Full scene adaptation

✔  One-year warranty

✔  Easy installation

  • Products
  • Technical Data
  • Downloads

Product description

▪ Load-bearing capacity 150kg, single door, double door, framed door and frameless glass door can be used

▪ Standard track length 4.2m, other optional lengths are 2.1m, 2.5m, 3m, 4m, 5m, 6m

▪ Can be used with different access control switches

▪ Microcomputer control system, can control the door body to operate in the set way, realize multiple interfaces such as double door interlocking, and at the same time come with power-on self-check, rebound when encountering resistance, to prevent accidents of pinching people.

▪ Adopting European motor design, integrated reduction box technology, strong drive, stable operation, and increased output power.

▪ Special reduction silent wheel, professional hanging design, roller interface effectively reduce operating noise.

▪ Multiple control program customization

▪ Customizable professional program controller, support bad debt, random stop, Bluetooth, CNC display and other control programs.

outus Automatic Sliding Glass Door Aluminum Sliding Door System unitoutus Automatic Sliding Glass Door Aluminum Sliding Door System unit

Authentication

  • 37e065c38b4547585a484da1fa9f8507_05f76470e0be25c47b9367570f6a7298fedfae6bbcf30ef6eb8529be79782d20.png
  • b5f393b269bf5e8d51b6e89c1c528ec7_d65c8bab529ec652803e5cb9bbb8fd48c9279075a1e028d0508739ab930a9c02.png
  • c7ca8fef69012b145ed5d14d3d7e4cde_8e984a55faaca405c6dc85016fe450b41332f8326da4eb81ca7679fd4ec4133d.png
  • fe82f6e36e5d684b7ac8aefe73f581a4_e7a0f5dbc3d83b3d06500f44462cb9cd20e66a2cc24e37f5c69e826f0dcb892f.png
  • d40f02898fd60c201144619c3edae6f9_c83e84ecffe0795637634b8890d67745dcf7dae738e879364cc08e105f0c26d9.png

Technical data

design style Modern
country of origin Jiangsu, China
brand OREDY
model ORD - 150
Maximum door weight (single) 1*150kg
Maximum door weight (double) 2*150kg
Door leaf length 600 - 2100mm
opening speed 15 - 50cm/s
closing speed 13 - 50cm/s
motor DC 24v brushless motor

Downloads

OREDY 2024

Installation Manual
