OUTUS Frameless Tempered Glass Sliding Door – 12mm Shop & Office CE

1. 12mm tempered safety glass: compliant with EN 12543 (EU) and ASTM C1048 (North America)

2. Available thickness: 8mm / 10mm / 12mm – specify load requirement and we advise

3. Full system supply: 12mm glass + aluminium frame + ORD operator + PIR sensor (one-order)

4. Custom size: width 600–5000mm, height 2000–3500mm – standard lead time 3 weeks

5. CE certified for public building use | Glass warranty: 2 years against spontaneous breakage

Products
Technical Data

Technical data

Parameter Category	Specification
Product Name	Automatic Frameless Glass Sliding Door
Main Material	8mm/10mm/12mm tempered glass (explosion-proof tempered glass optional)
Opening Mode	Automatic sliding (radar/infrared sensor activated)
Glass Transparency	High transmittance (≥85%)
Edge Treatment	Fine polishing, smooth without burrs
Guide Rail Material	Stainless steel (anti-rust, wear-resistant)
Pulley Material	Nylon + steel bearing (silent, smooth)
Drive System	DC brushless motor, low noise, stable operation
Sensing Mode	Radar sensor / Infrared sensor (optional)
Max Single Fan Size	Width ≤1500mm, Height ≤3000mm (customizable)
Operating Noise	≤55dB
Safety Features	Obstacle rebound, emergency stop, manual release
Power Supply	AC 110V/220V, 50-60Hz
Customization	Single/double fan, glass thickness, door size, sensing mode customizable
Applicable Scenarios	Shops, offices, exhibition halls, office buildings, commercial lobbies
Service Life	≥10 years (normal use, regular maintenance)
Maintenance Requirement	Regular lubrication of pulleys (once every 6-12 months); glass wiping; motor inspection (once a year)
Optional Accessories	Anti-collision strip, door stopper, glass film, handle

Product description

This Automatic Frameless Glass Door is a minimalist intelligent door designed for modern commercial spaces and high-end residential scenarios. It features a frameless integrated structure made of high-strength tempered glass, abandoning the constraints of traditional metal frames to achieve an extremely transparent visual effect and maximize space lighting and a sense of openness. The door is equipped with an intelligent sensor drive system, supporting radar/infrared sensing for automatic opening. Paired with precision silent guide rails and smooth pulley sets, it runs lightly without jitter and with low noise.

It can be customized with tempered/explosion-proof tempered glass specifications, combining high transparency and impact resistance to meet the safety needs of different scenarios. The product surface is finely polished with smooth edges without burrs, and the installation method is flexible. Single/double fan styles can be customized according to space size, perfectly suitable for shops, offices, exhibition halls, office buildings and other scenarios. It is an ideal modern door choice that balances appearance, intelligence and practicality.

Authentication

Automatic Frameless Glass Door Real Shot - Sensor Activated, Smooth & Silent!

The real-scene operation demo of this automatic frameless glass door is here!The video shows the complete operation process of the door in full: when pedestrians approach, the radar/infrared sensor triggers immediately, and the door automatically slides open smoothly. Equipped with precision guide rails and silent pulleys, it runs smoothly without jitter and with noise ≤55dB. When simulating an obstacle during closing, the door stops and rebounds immediately, providing comprehensive safety protection. Close-up shows the frameless all-glass transparent structure, which maximizes lighting and makes the space vision more open, and the minimalist design shows the modern light luxury texture; the fine polishing process of the glass edge is clearly presented, smooth without burrs.Made of high-strength tempered glass with optional explosion-proof version, the product has a stable and durable drive system, and can be customized with single/double fan. It is an ideal intelligent door choice for shops, offices, exhibition halls, office buildings and other scenarios, balancing appearance and intelligence!
