Automatic Sliding Door Biometric Face Recognition Access Control System Can Swipe Card

This is an access controller integrated with face + fingerprint recognition functions, featuring a 4.3-inch IPS full-view HD screen and a 2-megapixel wide dynamic binocular camera. Its hardware is equipped with a quad-core CPU (A7 1.2GHz), 1GB DDR3 + 8GB EMMC storage, and runs the LINUX system, ensuring stable and efficient performance.

The product supports TCP/IP and optional WiFi communication, and can store 3000 faces, 3000 cards, 2000 fingerprints, and 200,000 records. The recognition methods include 1:N and 1:1 modes, with a recognition speed of ≤0.3 seconds. It is equipped with Wiegand input/output interfaces, USB interface, etc., and is powered by DC12V/2A (wide range 5V-14V). The shell is made of ABS + acrylic material, with a size of 184×88×25mm and a weight of only 0.3KG. It adapts to the temperature range of -10℃~70℃, and is suitable for intelligent access control management in offices, parks, buildings and other scenarios.

  • Products
  • Technical Data
  • Downloads

Technical data

Model Face Recognition&Fingerprint Access Controller
Shell Material ABS + Acrylic Panel
Working Voltage DC12V/2A(DC9V-14V)
Working Temperature -10℃-70℃
Screen 4.3 Inches IPS Full View HD Screen
CPU 4 cores A7 1.2GHZ
Storage Capacity 1GB DDR3 + 8GB EMMC
GPU MAL400 II
Communication Way TCP/IP(WIFI Optional)
Operation System LINUX
Camera Wide Dynamic Binocular 2 megapixel HD camera
Liveness Detection Support
User Capacity 3000 Faces, 3000 Cards, 2000 Fingerprints
Records 200,000 Records
Recognition Way 1:N / 1:1
Identification Speed ≤0.3s
Wiegand Function One Group of Wiegand Input/Output(26/34)
Fingerprint Identification Support
Size 184×88×29mm
Weight 0.3KG

Product description

▪Accurate and Efficient Dual Recognition: Supports both face and fingerprint recognition, paired with a 2-megapixel wide dynamic binocular camera, with a recognition speed of ≤0.3 seconds. 1:N/1:1 modes adapt to different security needs.

▪HD Interactive Experience: 4.3-inch IPS full-view HD screen + voice prompts, intuitive feedback of operation status, combined with a metal texture recognition panel, ensuring smooth use and clear vision.

▪Powerful Hardware Performance: Quad-core A7 1.2GHz CPU + LINUX system, 1GB+8GB storage combination, stable operation without lag, supporting 200,000 records storage.

▪Flexible Communication and Expansion: Standard TCP/IP communication, optional WiFi module, and equipped with Wiegand interface and USB interface, adapting to various access control systems and data transmission needs.

▪Large-Capacity User Management: Can store 3000 faces + 3000 cards + 2000 fingerprints, meeting the personnel management needs of medium and large-scale places.

▪Environment and Installation Friendly: ABS + acrylic shell is durable and lightweight (only 0.3KG), wide temperature (-10℃~70℃) and wide voltage (5V-14V) adapt to complex scenarios, and small size is easy to install.
