Hospital Airtight Automatic Door - Single/Double Leaf Optional Brushless Motor Sealed Door

This medical airtight door is an intelligent automatic door specially developed for medical scenarios such as hospital operating rooms and clean rooms, with customized single/double leaf design and equipped with a long-life brushless motor. It realizes intelligent automatic control of the door leaf, which can automatically adapt to the running state and also support manual adjustment. The product innovatively adopts a U-shaped arc groove track + special rubber sealing strips around the door leaf, combined with a two-ground wheel lower guide rail structure, which perfectly meets the high airtightness requirements of medical scenarios and the special trajectory operation requirements of the door leaf. It opens and closes smoothly with low noise, is equipped with a lever-type/recessed handle for easy manual pushing and pulling when power is off, and adapts to the diverse installation and use needs of hospitals with a working temperature range of -20℃~+50℃. It is an exce

  • Products
  • Technical Data
  • Downloads

Product description

1.Professional high airtight performance, with special rubber sealing strips around the door leaf + U-shaped arc groove track, stable and reliable sealing, suitable for the clean requirements of operating rooms.

2.Equipped with brushless motor, long service life, no frequent replacement and maintenance, reducing the later use cost of hospitals.

3.Intelligent automatic control, the running state of the door leaf can be adjusted automatically, and manual adjustment is supported in special cases, adapting to the flexible needs of medical scenarios.

4.Smooth and low-noise opening and closing, no obvious abnormal noise during door operation, creating a quiet hospital treatment environment.

5.Two-ground wheel lower guide rail structure, accurately matching the special trajectory operation requirements of the door leaf, with more stable and accurate operation.

6.Single/double leaf optional, adapting to different door opening net widths of 900-1800mm, meeting the installation needs of different hospital spaces.

7.Emergency manual opening when power off, equipped with lever-type/recessed handle, easy to push and pull without power, ensuring smooth passage in medical scenarios.

8.Multi-parameter free adjustment, opening/closing speed and open time are adjustable, adapting to different pedestrian flows and usage scenarios in hospitals.

9.Safe operation protection, equipped with safety light and other protective designs, avoiding collision during operation, protecting the safety of medical staff and patients.

10.Stable operation in wide temperature range, working temperature from -20℃ to +50℃, adapting to different regional environments of hospitals without faults.

11.Surface installation method, simple installation process, no damage to the original wall structure, adapting to the on-site construction needs of hospitals.

12.Low power consumption and energy-saving design, the total power consumption of the whole machine is <180W, more energy-saving and environmentally friendly for long-term use.

Hospital Airtight Automatic Door - Single/Double Leaf Optional Brushless Motor Sealed DoorHospital Airtight Automatic Door - Single/Double Leaf Optional Brushless Motor Sealed Door
Why choose OuTus

Authentication

  • 37e065c38b4547585a484da1fa9f8507_05f76470e0be25c47b9367570f6a7298fedfae6bbcf30ef6eb8529be79782d20.png
  • b5f393b269bf5e8d51b6e89c1c528ec7_d65c8bab529ec652803e5cb9bbb8fd48c9279075a1e028d0508739ab930a9c02.png
  • c7ca8fef69012b145ed5d14d3d7e4cde_8e984a55faaca405c6dc85016fe450b41332f8326da4eb81ca7679fd4ec4133d.png
  • fe82f6e36e5d684b7ac8aefe73f581a4_e7a0f5dbc3d83b3d06500f44462cb9cd20e66a2cc24e37f5c69e826f0dcb892f.png
  • d40f02898fd60c201144619c3edae6f9_c83e84ecffe0795637634b8890d67745dcf7dae738e879364cc08e105f0c26d9.png

Technical data

Parameter Item Single Leaf Type Double Leaf Type Universal Parameters
Door Leaf Weight 100kg 2×80kg -
Clear Width of Door Opening 900~1500mm 1200~1800mm -
Clear Height of Door Opening 2000~2400mm 2000~2400mm -
Installation Method - - Surface Mounting
Power Supply Voltage - - AC220V±10%, 50~60Hz
Door Opening Speed - - 30~60cm/s Adjustable
Door Closing Speed - - 30~60cm/s Adjustable
Open Time - - 0~9s Adjustable
Manual Thrust - - <100N
Total Power Consumption - - <180W
Working Ambient Temperature - - -20℃~+50℃
Sealing Performance - - Stable, Reliable
Motor Type - - Brushless Motor
