| Item | Type / Specification Range | Remarks |
| Profile Material | Aluminum alloy 6063-T5 (or 6005, etc.) | Common durable aluminum material |
| Thermal Break Profile | Yes (thermal barrier strip width ≥ 12mm) | Improves insulation performance |
| Profile Wall Thickness | 1.6–2.4mm | Selected according to project requirements |
| Door Leaf / Frame Depth | 60–120mm (series 70/80/90, etc.) | Different series have different structures |
| Glass Structure | Tempered glass, commonly 5mm+12A+5mm or double glazing (5mm+20A+5mm) | Used for sound and heat insulation |
| Track / Roller System | Steel + stainless steel / brass rollers | Smooth sliding, durable |
| Maximum Size Reference | Width up to ~3000mm or multi-panel combination | Customizable per project |
| Sealing Performance | Wind, air, and water tightness performance levels | e.g., Uw≈2.0W/m²·K |
| Color / Surface Treatment | Powder coating, anodizing, wood grain options | Highly customizable |
| Hardware Accessories | Multi-point lock, roller, sealing strip, mosquito screen optional | Varies by configuration |
| Application Scenarios | Residential, villas, apartments, commercial buildings, offices | Widely applicable |
Aluminum alloy sliding windows (also called push-pull windows) are a common type of window in home decoration. Their main advantages are space saving and easy operation. According to their design and thermal insulation performance, they can be divided into ordinary aluminum alloy sliding windows and thermally insulated aluminum alloy sliding windows.
