DC800 Gate Motor 600kg Load - Built-in Backup Power & Solar Compatible

1. Pure Copper Core Motor, Powerful & Durable

The core motor uses pure copper windings for high conductivity and low heat generation. With 280W power, it can stably drive 600kg gates, and the motor speed reaches 2400r/min, suitable for high-frequency opening/closing scenarios like factories and parks. Its service life is 30% longer than ordinary copper-clad aluminum motors.

2. Dual Voltage + Multi-Energy Compatibility, Strong Scene Adaptation

Supports dual AC voltages (AC 110V/220V, compatible with global mainstream power grids), can connect to 28-36V solar panels for green power supply, and matches DC24V control boards. Balancing industrial power supply and new energy needs, it adapts to power environments in different regions.

3. Manual Emergency + Backup Power, No Downtime on Power Outage

Equipped with a hex wrench-controlled clutch (clockwise unlocking for manual gate operation) and built-in lithium battery backup (supports 3-5 days of operation after power failure), it avoids gate inoperability due to sudden power outages, ensuring traffic efficiency at park/factory entrances.

4. Multiple Safety Protections, Safer to Use

Mechanical Protection: Welded limit stop iron on the track side to prevent gate tipping when electrical limit fails;

Electrical Protection: Motor grounding and leakage/short-circuit protection to avoid electric shock risks;

Intelligent Protection: Limit magnets precisely control gate stroke to prevent overtravel damage, and support infrared sensor access (optional) for automatic reversal when obstacles are detected.

5. Low-Maintenance Design, Reduce Later Costs

The housing is made of high-strength aluminum alloy (corrosion-resistant, impact-resistant), with advanced grease filling (lifetime no replacement/addition). Only regular anti-rust grease application to the clutch keyhole is needed, reducing daily maintenance frequency and costs.

Products
Technical Data
Downloads

Technical data

Parameter Item	Detailed Specification
Voltage Compatibility	AC 110V/60Hz, AC 220V/50Hz (dual voltage); Control board voltage: DC24V
Motor Power	280W
Operating Speed	16m/min
Applicable Gate Weight	Max 600kg
Motor Speed	2400r/min
Ambient Temperature	-25℃ ~ +70℃
Net Weight	11.6kg
Safety Configuration	Limit magnet (stroke control), leakage/short-circuit protection, grounding protection, track limit stop iron
Backup Power Supply	Built-in lithium battery (supports 3-5 days of operation after power failure)
Solar Compatibility	Supports 28-36V solar panel connection
Installation Reserved Wire	1mm² ×6 cores (or 1.5mm² 2-core wire)

Product description

The DC800 Gate Motor is a high-durability driving device designed specifically for sliding gates. It features a pure copper core motor as the core, paired with a high-strength aluminum alloy housing, worm gear reducer, and overrunning friction clutch, combining strong power and stable performance. The device supports dual AC voltage compatibility (AC 110V/60Hz, AC 220V/50Hz) and is compatible with a DC24V green control board. It can drive gates up to 600kg with an operating speed of 16m/min, meeting the needs of medium-to-heavy sliding gate scenarios such as factory gates, park entrances, and large warehouses. Integrated with manual emergency clutch (for manual gate operation during power outages), built-in lithium battery backup (supports 3-5 days of emergency operation after power failure), and solar compatibility (fits 28-36V solar panels), it also includes safety devices like limit magnets and leakage/short-circuit protection. Balancing efficient driving, safety protection, and green energy adaptation, it is a professional driving solution for sliding gates in industrial and commercial scenarios.

Authentication

Dual Control Mode Show - Remote vs Wireless Keyboard for Courtyard Gate

Comprehensive wireless control test & demo of this automatic sliding courtyard gate is here! The video shows the real-world performance of both control modes throughout:First, the wireless remote test: From a distance of 50 meters with no obstacles, lightly press the remote button, and the door responds instantly to slide open with stable signal transmission without interference. It also demonstrates through-the-wall remote control, which triggers accurately even through a solid wall, adapting to large villa spaces and long-distance outdoor management.Next, the wireless keyboard demo: Connect the control terminal via a wireless keyboard, and input commands to realize uniform door opening/closing and precise stroke control with intuitive operation, suitable for scenarios requiring manual programmed control. Throughout the video, both wireless remote and wireless keyboard show low-noise operation and zero-jitter response. With IP44 dustproof and waterproof rating, it adapts to complex outdoor environments. It is a high-quality choice for intelligent entrance and exit control in villa courtyards and commercial venues, offering flexible and safe operation!
